Use Chamfers to Hide a Poorly Aligned Panel Glue-Up

bguphoto1

Photo 1: This uneven woodworking glue-up almost de-railed my project.The boards slipped just a tiny bit, and I would have to remove a lot of wood to get this tabletop flat. But once flat, my piece would be too thin. I needed a better solution.

Small chamfers fix a gluing mistake.I’m under the gun. This small end table is the perfect gift for an old college friend, but I only have a couple of days left to complete the task. The only thing left before finishing is to square up and sand the top. Aaaagh! In my haste, I haven’t noticed that my woodworking glue-up has slipped and the tabletop is uneven by about 1/16″ on the top and bottom.This piece will be too thin if I face the bottom and plane the top perfectly flat. I don’t have enough time to go out and buy wood and then wait for it to acclimate to my shop; heck, I don’t even have enough time to glue up another panel and wait for it to dry.

What a bind! Now is my chance to borrow an old trick from the Stickley Brothers. In admiring some of their antiques, I’ve noticed that they truly differentiated between visible and hidden surfaces. I need to do the same here.

Fixing a Bad Glue Up on Your Woodworking Project

Photo 2: I plane the proud board even with the adjacent boards, making sure to avoid tearing out by using a sharp blade

Rather than flatten the bottom and top, I decide only to flatten the top. I clamp the work piece to my bench, but bench dogs and a vise would also work great. I use a freshly honed blade and plane in the direction of the wood (Photo 2). Remember, I want to maximize the thickness of the top, so I avoid tear-out as much as possible.

Fixing a Bad Glue Up on Your Woodworking Project

Photo 3: I check flatness with a straightedge.

Next, I check the flatness of the panel with a straightedge (Photo 3). Once the tabletop is flat, I square it up, and while doing, so I remove the most uneven parts from the bottom. Then I sand the top to final smoothness.

Fixing a Bad Glue Up on Your Woodworking Project

Photo 4: I plane the bottom of the work-piece with a small hand plane. The transition between pieces is a little rough, but eventually the chamfer smooths the different levels. A no-slip drawer liner is the perfect "clamp"

I chamfer the bottom edge of the work-piece using a hand plane (Photo 4). At first, the planning is a bit choppy as the plane transitions between the uneven boards, but eventually the uneven surface ‘disappears’ and my plane slides smoothly along the end of the piece. I remove an equal amount from each proud piece to make a consistent chamfer along the end of the board. I continue this chamfer around the perimeter of the piece.

Fixing a Bad Glue Up on Your Woodworking Project

Photo 5: Plane a light chamfer on the top. This not only softens the edge, but also gives the illusion of a thicker top. The uneven bottom is hidden by the first chamfer and will never be seen in its final application as a low tabletop.

Once the bottom has a consistent chamfer, I flip it over to inspect my work. The unevenness is impossible to see. It does appear a touch thin, so I employ an old visual trick by chamfering the top (Photo 5). I only add a small chamfer, but if I wanted the illusion of a much thicker top, I could plane a larger, wider chamfer.

Discretion should be used when employing this technique, as it is perfect for a small end table, or even for a floating panel in a cabinet, but not for a dining table. The edge of a dining table top is felt and caressed, whereas the inside of a panel or the underside of an end table is rarely seen or handled. Once this piece is affixed to its low table apron, it is truly invisible.

Instead of missing my college buddy’s birthday, I’m able to give him his gift on time, thanks to this simple but effective repair.
